2-2. Tube Cassette Refill Instruction
1. Press the green cassette fixed
latch to pull out the cassette at
an upwardly slanted angle.
2. Refill coins into tube cassette
and ensure that the coins enter
the corresponding tubes and
flatly placed. Then place the
tube cassette back to Changer.
*You may choose coin refill mode to fill coins without open tube
cassette.
Latch
2-3. Installation Checklist
Check that there is a 3 to 5 mm gap between
the coin changer return lever and the vending
machine return mechanism.
3-5 mm
-4-
CC6100
