ELECTRIC BICYCLE METER KT—LCD3 Product User Manual
- 29 -
0 Function off
1 Function on
Please Note
The motor operating temperature display requires installing temperature
sensor in the motor, output temperature detection signal simultaneously.
After finishing C8 parameter setting, hold button (SW) shortly to save the
current set values and enter C9 parameter setting interface.
○ C9 Startup Password Setting Mode
Enter C9 parameter setting interface after C8 parameter setting is finished, C9
parameter column flashes.
C9 parameter setting interface
C9 is meter power-on password setting mode. The default value is 0, hold
button (UP) or button (DOWN) shortly for selection.
C9 parameter definition table
C9 value Startup password setting
0 Function off
1 Function on
When C9 setting is 1, hold button (SW) shortly, indicating that the password
function is startup, and then enter the password settings interface, three password setting
columns flash.
//
[
