ELECTRIC BICYCLE METER KT—LCD3 Product User Manual
- 32 -
parameter copy), there’s source logo on display interface.
Data Source Display Interface
After finishing C11 parameter setting, hold button (SW) shortly to save the
current set values and enter C12 parameter setting interface.
○ C12 Controller Minimum Voltage Adjustment Mode
Enter C12 parameter setting interface after C11 parameter setting is finished, C12
parameter column flashes.
C12 parameter setting interface
C12 is controller minimum operating voltage adjustment mode (tiny adjustment of
voltage shortage). The default value is 4, and the setting range is 0-7, hold button
(UP) or button (DOWN) shortly for selection.
C12 parameter definition table
C12 value
Minimum Voltage(V)
24V Controller 36VController 48VController
0 Default value-2V Default value-2V
Default value-2V
1 Default value-1.5V
Default
value-1.5V
Default
value-1.5V
'
