Ideal Boilers Atlantic 35 - SECTION 1 - GENERAL

8
Installation and Servicing
SECTION 1 - GENERAL
Note. Gas consumption is calculated using a
caloric value of 38.7 MJ/m
3
(1038 Btu/ft
3
) gross
or 34.9 MJ/m
3
(935 Btu/ft
3
) nett
To obtain the gas consumption at a different
caloric value:
a. For l/s - divide the gross heat input (kW) by
the gross C.V. of the gas (MJ/m
3
)
b. For ft
3
/h - divide the gross heat input (Btu/h)
by the gross C.V. of the gas (Btu/ft
3
)
c. For m
3
/h - multiply l/s by 3.6.
Key to symbols
GB = United Kingdom IE = Ireland (Countries of destination)
PMS = Maximum operating pressure of water
C
13
C
33
C
53
= A room sealed appliance designed for connection via ducts to a
horizontal or vertical terminal, which admits fresh air to the burner
and discharges the products of combustion to the outside through
orices which, in this case, are concentric. The fan is up stream of
the combustion chamber.
I
2H
= An appliance designed for use on 2nd Family gas, Group H only.
* The value is used in the UK Government’s Standard Assessment Procedure (SAP) for energy rating of dwellings. The test data from
which it has been calculated have been certied by a notied body.
ATLANTIC COMBI
24 30 35
Gas supply 2H - G20 - 20mbar
Gas Supply Connection 15mm copper compression
Injector Size mm 4.15 4.65 4.9
Inlet Connection DHW 15mm copper tail
Outlet Connection DHW 15mm copper compression
Flow Connection CH 22mm copper compression
Return Connection CH 22mm copper compression
Flue Terminal Diameter mm (in) 100 (4)
Average Flue Temp-Mass Flow Rate (DHW) 63
o
C - 11g/s 68
o
C - 13g/s 73
o
C - 15g/s
CO2 Content (± 0.7) Max. DHW 9.5% 9.3% 9.5%
Min. CH 8.8% 8.8% 8.9%
Maximum Working Pressure (Sealed Systems) bar (lb/in
2
) 2.5 (36.3)
Maximum DHW Inlet Pressure bar (lb/in
2
) (kPa) 10.0 (145) (1000)
Minimum DHW Inlet Pressure* bar (lb/in
2
) (kPa) 0.8 (11.6) (80) 1.3 (18.9) (130) 1.3 (18.9)** (130
Minimum DHW Inlet Pressure to operate at 0.6bar system pressure All Model sizes 0.5 bar
Electrical Supply 230 V ~ 50 Hz.
Power Consumption W 96 98 107
Fuse Rating External : 3A Internal : T4H HRC L250 V
Water content CH litre (gal) 1.2 (0.26)
DHW litre (gal) 0.5 (0.11)
Packaged Weight kg 33.7 33.7 33.8
Maximum Installation Weight kg 29.9 29.9 30
Boiler Casing Size Height mm 700
Width mm 395
Depth mm 285
Table 1 - General Data
*Required for maximum ow rate. Boiler operates down to 2 l/min DHW delivery
** In areas of low water pressure the DHW restrictor can be removed
Max. Min.
Boiler Input : 24 30 35
Boiler Input ‘Q’ Nett CV kW 24.3 4.9 6.1 7.1
Gross CV kW 27.0 5.4 6.7 7.9
Gas Consumption m
3
/h 2.512 0.500 0.627 0.734
(ft
3
/h) (89) (17.8) (22) (25.9)
Boiler Output :
Non Condensing kW 24.2 4.8 6.1 7.1
70
o
C Mean Water temp.
Condensing kW 25.6 5.1 6.4 7.5
40
o
C Mean Water temp.
Seasonal efciency* SEDBUK 2005 91% 91.1% 91%
Seasonal efciency* SEDBUK 2009 89% 89% 88.9%
NOx Classication CLASS 6
24 30 35
Maximum DHW Input :
Nett CV kW 24.3 30.4 35.4
Gross CV kW 27.0 33.7 39.3
Gas Consumption m
3
/h 2.512 3.135 3.657
(ft
3
/h) (89) (111) (129)
Maximum DHW Output kW 24.2 30.3 35.3
DHW Flow Rate at 35º
Temp Rise
l/min
(gpm)
9.9
(2.2)
12.4
(2.8)
14.5
(3.2)
DHW Specic Rate l/min
(gpm)
11.5
(2.5)
14.5
(3.2)
16.9
(3.7)
Table 2 - Performance Data - Central Heating Table 3 - Performance Data - Domestic Hot Water
