Ideal Boilers Minimizer FF 50 - PARTS AND ASSEMBLY INFORMATION; Short List of Parts

47
Minimiser - Installation
The following are parts commonly required as replacements, due to damage
or expendability. Their failure or absence is likely to affect the safety and/or
performance of this appliance.
The list is extracted from the British Gas List of Parts which contains all
available spare parts.
The full list is held by British Gas, Caradon Ideal distributors and merchants.
SHORT LIST OF PARTS
When ordering spares please quote:
1. Boiler model.
2. Appliance G.C. number.
3. Description.
4. Quantity.
5. Product No.
Key No. G.C. Part No. Description Qty. Product No.
1 Main burner
. Bray No. AB 6600 FF 30 1 076 527
. Bray No. AB 6603 FF 40 1 076 753
. Bray No. AB 6601 FF 50 1 076 754
. Bray No. AB 6604 FF 60 1 076 755
. Bray No. AB 6602 FF 70 - 80 1 076 756
2 Main burner injector
398 043 Bray Cat. 10 size 800 FF 30 1 004 858
393 050 Bray Cat. 10 size 1150 FF 40 1 003 205
390 058 Bray Cat. 10 size 1600 FF 50 1 003 362
398 059 Bray Cat. 10 size 1700 FF 60 1 004 305
. Bray Cat. 10 size 3000 FF 70 1 112 935
. Bray Cat. 10 size 2700 FF 80 1 112 936
3 . Gas control valve - SIT NOVAMIX 0828110 1 076 757
4 . Control box, including control thermostat, printed circuit
board and 'Burner on' neon 1 111 781
5 . Flame detection electrode and gasket
MORGAN MATROCK No. SKNP 2505 1 076 758
6 . Spark electrode - MORGAN MATROCK No. SKNP 2504
and gasket 1 076 816
7 . 'Burner on' neon assembly - READILEADS 1 138 139
8 . Pressure switch - SIT.0380.048 1 112 417
9 . Automatic ignition printed circuit board - PACTROL PCB No. 37 1 111 748
10 . Spark generator assembly - PACTROL 1 112 216
11 . Control thermostat - RANCO K36P1331 1 111 853
12 382 873 Overheat thermostat - ELMWOOD 2455 RM-98727 1 076 817
13 . Dry fire thermostat - RANCO LM7 P5077 1 111 854
14 . Flue thermostat - ELMWOOD 1 138 097
15 . Siphon assembly - ALTEKNIC 1 076 819
16 . Control thermostat knob 1 111 904
17 . Fan assembly - SIFAN No. WFFB 0226 018 FF 30 1 138 125
. SIFAN No. WFFB 0226 018 FF 40 1 138 126
. SIFAN No. WFFB 0226 019 FF 50 1 138 127
SIFAN No. WFFB 0226 019 FF 60 1 138 128
SIFAN No. WFFB 0226 020 FF 70 1 138 129
SIFAN No. WFFB 0226 020 FF 80 1 138 130
18 . Boiler front panel, painted white with bottom trim 1 112 584
19 . Controls pod door, painted white 1 076 820
20 . Boiler bottom panel, painted white 1 076 821
21 . Control panel, painted white 1 076 822
22 . Casing seals Long (sides) 1 076 823
Short (top, bottom) 1 076 823
23 . Burner sensing pipe 1 076 824
24 . Fan pressure sensing pipe 1 076 902
