Concord CXi - Installation
When ordering spare parts please quote:
1. Boiler model
2. Boiler serial no. (refer to the data plate on the combustion chamber)
3. Boiler P.I. No. (refer to the data plate on the combustion chamber)
4. Description
5. Quantity
6. Product no.
Key No. Description Qty. Product No.
Gas valve
28 HONEYWELL Hi/Lo VR4605P B2003 CXi 110, 120, 140, 160 & 180 1 111 867
28A HONEYWELL VR4605 A 1104 ..................................... CXi 110 1 138 896
HONEYWELL VR4605 A 1104 ..................................... CXi 120 1 138 896
HONEYWELL VR4605 A 1104 ..................................... CXi 180 2 138 896
28B HONEYWELL VR4605 AB 1019 ................................... CXi 140 & 160 1 111 896
28C Plug - gas valve ..................................................... CXi 110, 120, 140, 160 & 180 1 111 872
28D Plug and lead - gas valve ...................................... CXi 110, 120, 140 & 160 1 139 269
28E Plug and lead - gas valve ...................................... CXi 110, 120, 140 & 160 1 112 431
28F Plug and lead - gas valve ...................................... CXi 110, 120, 140, 160 & 180 1 139 270
28G Plug and lead - gas valve ...................................... CXi 180 1 111 870
29 Spark generator 1 139 300
31 Injector 4.02 mm diameter ......................................................... CXi 110 6 013 175
Injector 4.2mm diameter ............................................................ CXi 120 6 013 180
................................................................................................... CXi 140 7 013 180
................................................................................................... CXi 160 8 013 180
................................................................................................... CXi 180 9 013 180
32 Flame detection electrode 1
33 Main burners ............................................. Worgas CXi 110 5 138 663
.................................................................. Worgas CXi 120 5 138 663
.................................................................. Worgas CXi 140 6 138 663
.................................................................. Worgas CXi 160 7 138 663
.................................................................. Worgas CXi 180 8 138 663
34 Main burner (RH end)................................ Worgas CXi 110 - 180 1 138 664
36 Ignition electrode 1 112 365
45 Control box assembly complete 1 138 695
46 Thermistor 1 112 289
47 PCB 34 1 069 957
48 PCB 35 1 069 960
49 Real time clock 1 069 958
50 PCB 34 and real time clock 1 069 959
51 Ribbon cable 1 069 961
SHORT LIST OF PARTS
The following are parts commonly
required as replacements, due to damage
or expendability.
Their failure or absence is likely to affect
the safety and/or performance of this
appliance.
