EVOMAX 2 30 - 150 kW (Natural Gas & LPG)
GENERAL DATA
MODEL 30/30P 40/40P 60/60P 80/80P 100/100P 120/120P 150
Gas Supply 2H - G20 - 20mbar / 3P - G31 - 37mbar
Gas Supply
Connection
G ¾
Flow Connection G1 ¼
Return Connection G1 ¼
Max Pressure
(sealed system)
Bar (psi) 6
Maximum Static Head m 61
Electricity Supply 230V - 50Hz
Fuse Rating A 4.0
Power Consumption W 81 138 82 149 187 243 240
IP Rating IPX4D
Nominal Flue Size
(concentric)
mm 80/125* 100/150
Condensate Drain mm 25
Water Content l 3.0 5.0 7.0 9.2
Dry Weight Kg 47.5 57..5 73.0 81.0
*Optional kit available on 60kW and 80kW models for 100/150mm flue
BOILER EVOMAX 2
Remote indication (run & alarm)
Hours run
BMS (0-10v) operation
Pump overrun
Large backlit LCD controls,
including 5 line plain text display
Dynamic control menu set up
BOILER EVOMAX 2
Multi boiler frame & header
kits (see pages 12-15)
Varican Module Master Kit
Varican Module Slave Kit
Extension Module Kit
OPENTHERM Room Control Kit
Room Sensor Kit
Tank Sensor Kit
Outside Sensor Kit
Header Flow Tank Immersion Sensor Kit
Header Flow Tank Strap On Sensor Kit
Safety Interlock Kit
0-10V Pump Control Kit
Condensate Pump
INCLUDED AS STANDARD
OPTIONAL KITS
