IDEAL he24 Installation And Servicing

59
FAULT FINDING
FAULT FINDING FAULT FINDING FAULT FINDING FAULT FINDING FAULT FINDING
Esprit - Installation and Servicing
84 FAULT FINDING CHART MAIN MENU
ALTERNATING 'L' 'F'
GO TO FRAME 85
ALTERNATING 'L' 'E'
GO TO FRAME 86 OR 88
ALTERNATING 'L' 'A'
GO TO FRAME 87 OR 88
ALTERNATING 'L' '8'
GO TO FRAME 89
ALTERNATING 'H' '1'
GO TO FRAME 90
ALTERNATING 'H' '2'
GO TO FRAME 91
ALTERNATING 'H' '3'
GO TO FRAME 92
ALTERNATING 'H' '4'
GO TO FRAME 93
ALTERNATING 'H' 'F'
GO TO FRAME 94
In order to assist fault finding the boiler has an LED diagnostic display. The key to the display codes is as follows:
ALTERNATING 'H' 'n'
GO TO FRAME 95
ALTERNATING 'H' 'E'
GO TO FRAME 86
ALTERNATING 'H9'
GO TO FRAME 93
ALTERNATING 'L9'
GO TO FRAME 93

IDEAL he24 Specifications

General

Fuel Type	Natural Gas
Central Heating Output	24 kW
Dimensions (H x W x D)	700 x 395 x 278 mm
Boiler Type	Combi
Mounting	Wall Mounted
ERP Rating	A
DHW Output	24 kW
Efficiency Rating	A
