GENERAL
icos system - Installation and Servicing
Boiler Size HE15 HE24
Gas supply 2H-G20-20mbar
Gas Supply Connection Rc1/2 (1/2" BSP Female)
Injector size Stereomatic 5.6mm dia.
Flow Connection Central Heating 22mm copper compression
Return Connection Central Heating 22mm copper compression
Flue Terminal Diameter mm (in) 100 (4)
Maximum Working Pressure (Sealed Systems) bar (lb/in
2
) 2.5 (36.3)
Electrical Supply / Power consumption 230 V ~ 50 Hz. / 148 W
Fuse Rating External : 3A Internal : T3.15A L 250V
Water content Central Heating litre (gal) 2.0 (0.44)
Packaged Weight kg (lb) 50 (110)
Maximum Installation Weight kg (lb) 40 (88)
Boiler Casing Size Height mm (in) 687 (27)
Width mm (in) 390 (15 3/8)
Depth mm (in) 278 (11)
Table 1 - General Data
Note. Gas consumption is calculated using a
calorific value of 38.7 MJ/m
3
(1038 Btu/ft
3
)
gross or 34.9 MJ/m
3
(935 Btu/ft
3
) nett
To obtain the gas consumption at a different
calorific value:
a. For l/s- divide the gross heat input (kW) by
the gross C.V. of the gas (MJ/m
3
)
b. For ft
3
/h - divide the gross heat input (Btu/
h) by the gross C.V. of the gas (Btu/ft
3
)
Key to symbols
GB = United Kingdom IE = Ireland (Countries of destination)
PMS = Maximum operating pressure of water
C
13
C
33
C
53
= A room sealed appliance designed for connection via ducts to a
horizontal or vertical terminal, which admits fresh air to the burner
and discharges the products of combustion to the outside through
orifices which, in this case, are concentric. The fan is up stream of
the combustion chamber.
I
2H
= An appliance designed for use on 2nd Family gas, Group H only.
* The value is used in the UK Government's Standard Assessment Procedure (SAP) for energy rating of dwellings. The test data from
which it has been calculated have been certified by a notified body.
CAUTION. To avoid the possibility of injury during the installation, servicing or cleaning of
this appliance care should be taken when handling edges of sheet steel components.
Boiler Size HE15 Max HE24 Max HE15, HE24 Min
Boiler input 'Q' = Nett CV kW 15.1 24.4 9.1
Btu/h 51,500 83,300 31,000
Gross CV kW 16.8 27.1 10.1
Btu/h 57,200 92,500 34,400
Boiler output 'P' = Gas consumption l/s (cu.ft/h) 0.43 (54.7) 0.70 (89.0) 0.26 (33.2)
70
o
C Mean water kW 14.6 23.4 8.8
temperature Btu/h 50,000 80,000 30,000
40
o
C Mean water kW 15.5 25.1 9.6
temperature Btu/h 53,000 85,700 32,800
Seasonal efficiency (SEDBUK) * Band A [90.4]% [90.2]%
NOx classification Class 5
Table 2 - Performance Data
