LIST OF PARTS
icos system - Installation and Servicing
Ecl 1598
88
BOILER CASING ASSEMBLY
1. Front casing panel with screws.
2. Sealing panel with screws.
4. Bottom panel with screws.
89
CONTROLS ASSEMBLY
33. Controls assy with screws.
34. Controls hinge bracket.
35. User controls (without item 38).
36. PCB (primary controls).
38. User controls housing
39. Mains switch.
54. Jumper link (not shown)
90
BURNER ASSEMBLY
11. Burner assembly with screws and gasket.
