23 CONNECTING THE FLUE TO THE BOILER
Notes.
• Before tting the ue turret ll the
condensate trap within the boiler by
pouring a cupful of water into the ue
outlet (shown below). Take care to
ensure that the water is only poured into
the ue outlet, and does not spill into the
boiler casing.
• During assembly check that ue seals do
not become dislodged.
1. 

2. 
3. 



4. 




5. 


6. 

Note - Flues over 1 metre long





2
3G9847a
3
3G9847b
205367-9847d
Flue Outlet
4
3G9847d
5
3G9847e
6
Plastic Pegs
(assembled)
Retaining Clip
(assembled)
10120-205367
NOTE. SIDE FLUE
Select the orientation
before inserting turret into
boiler ue manifold.
DO NOT twist the turret
once inserted.
205367-3.indd 23 13/12/2010 16:21:17
