65
BOILER SEALING PANEL SEAL REPLACEMENT
1. Refer to Frame 51.
2. Remove the old seal from the casing and
thoroughly clean the casing surfaces.
3. Fit the new seal, ensuring the bottom joint
provides an air tight seal.
5. Reassemble in reverse order.
6. Check operation of the boiler. Refer to
Frames 40 & 41.
Note. Ensure that the boiler front panel is
correctly sealed, compressing the seal
to make an airtight joint.
SERVICING
