Installation and Servicing
SECTION 1 - GENERAL
Note. Gas consumption is calculated using a caloric value of
38.7 MJ/m
3
(1038 Btu/ft
3
) gross or 34.9 MJ/m
3
(935 Btu/ft
3
) nett
To obtain the gas consumption at a different caloric value:
a. For l/s - divide the gross heat input (kW) by the gross C.V.
of the gas (MJ/m
3
)
b. For Btu/h - multiply the gross heat input (kW) by 26.8
c. For ft
3
/h - divide the gross heat input (Btu/h) by the gross
C.V. of the gas (Btu/ft
3
)
d. For m
3
/h - multiply l/s by 3.6
Key to symbols
GB = United Kingdom IE = Ireland (Countries of destination)
PMS = Maximum operating pressure of water
C13 C33 C53 = A room sealed appliance designed for connection via ducts
to a horizontal or vertical terminal, which admits fresh air to
the burner and discharges the products of combustion to the
outside through orices which, in this case, are concentric.
The fan is up stream of the combustion chamber.
I
2H
= An appliance designed for use on 2nd Family gas, Group H only.
* The value is used in the UK Government’s Standard Assessment Procedure (SAP) for energy rating of dwellings. The test data from
which it has been calculated have been certied by a notied body.
Table 1 - General Data
*Required for maximum ow rate. Boiler operates down to 2 l/min DHW delivery
** In areas of low water pressure the DHW restrictor can be removed
Table 2 - Performance Data - Central Heating
Boiler Input : Max. Min.
24 30 35
Boiler Input ‘Q’ Nett CV kW 24.3 4.9 6.1 7.1
Gross CV kW 27.0 5.4 6.7 7.9
Gas Consumption m
3
/h 2.512 0.500 0.627 0.734
(ft
3
/h) (89) (17.8) (22) (25.9)
Boiler Output :
Non Condensing kW 24.2 4.8 6.1 7.1
70
o
C Mean Water temp.
Condensing kW 25.6 5.1 6.4 7.5
40
o
C Mean Water temp.
Seasonal efciency* SEDBUK 2005 91.1% 91.1% 91.1%
Seasonal efciency* SEDBUK 2009 89.6% 89.6% 89.6%
NOx Classication CLASS 5
Maximum DHW Input : 24 30 35
Nett CV kW 24.3 30.4 35.4
Gross CV kW 27.0 33.7 39.3
Gas Consumption m
3
/h 2.512 3.135 3.657
(ft
3
/h) (89) (111) (129)
Maximum kW 24.2 30.3 35.3
DHW Output
DHW Flow Rate l/min 9.9 12.4 14.5
at 35°C temp. rise. (gpm) (2.2) (2.8) (3.2)
DHW Specic Rate l/min 11.5 14.5 16.9
(gpm) (2.5) (3.2) (3.7)
Table 3 - Performance Data - Domestic Hot Water
24 30 35
Gas supply 2H - G20 - 20mbar
Gas Supply Connection 15mm copper compression
Injector Size mm 4.15 4.65 4.9
Inlet Connection Domestic Hot Water 15mm copper compression
Outlet Connection Domestic Hot Water 15mm copper compression
Flow Connection Central Heating 22mm copper compression
Return Connection Central Heating 22mm copper compression
Flue Terminal Diameter mm 100
Average Flue Temp-Mass Flow Rate (DHW) 63ºC - 11g/s 68ºC - 13g/s 73ºC - 15g/s
CO
2
Content (± 0.7) Max. DHW 9.5% 9.3% 9.5%
Min. CH 8.8% 8.8% 8.9%
Maximum Working Pressure (Sealed Systems) bar (lb/in
2
) 2.5 (36.3)
Maximum Domestic Hot Water Inlet Pressure bar (lb/in
2
) (kPa) 10.0 (145) (1000)
Minimum Domestic Hot Water Inlet Pressure* bar (lb/in
2
) (kPa) 0.8 (11.6) (80) 1.3 (18.9) (130) 1.3 (18.9)** (130)
Minimum DHW Inlet Pressure to operate at 0.6bar system pressure All Model sizes 0.5 bar
Electrical Supply 230 V ~ 50 Hz
Power Consumption W 94 101 114
Fuse Rating External : 3A Internal : T4A HRC L250 V
Water content Central Heating litre (gal) 1.2 (0.26)
Domestic Hot Water litre (gal) 0.5 (0.11)
Packaged Weight kg 33.7 33.8 33.9
Maximum Installation Weight kg 28.9 29 29.1
Boiler Casing Size Height mm 700
Width mm 395
Depth mm 278
