INSTALLATION
Solar Thermal - Installation and Servicing
23
IN ROOF MOUNTING (TS 8001)
21. Slide in the middle cover on the left.
22. Slide in the middle cover to the centre.
23. Slide in the middle cover on the right
24. Tighten the left and right middle cover to the side tin cover strip
and the collector on the required position using a self-drilling
sealed plumbing screw 4.5*35
21
22
23
24
INSTALLATION
