Configuring the Start Function
The start function is configured by means of the start function selector.
A start function with dynamization is typically if the start input is connected to a start push-button.
A start function without dynamization is typically used if the start input is connected to a logic
controller. Refer to the chapter Dynamization
(see page 43) for details.
Position of start function selector Configured start function
1
 Automatic/manual start (depends on
sensor/device connected to start input)
 Without startup test
 With dynamization
2
 Automatic/manual start (depends on
sensor/device connected to start input)
 With startup test
 With dynamization
3
 Monitored start
 Without startup test
 With dynamization
4
 Monitored start
 With startup test
 With dynamization
5
 Automatic/manual start (depends on
sensor/device connected to start input)
 Without startup test
 Without dynamization
6
 Automatic/manual start (depends on
sensor/device connected to start input)
 With startup test
 Without dynamization
7
 Monitored start
 Without startup test
 Without dynamization
8
 Monitored start
 With startup test
 Without dynamization
