HR9Z-B2192 8/2020 75
Chapter 7
Diagnostics
What Is in This Chapter?
This chapter contains the following topics:
WARNING
INEFFECTIVE SAFETY-RELATED FUNCTION AND/OR UNINTENDED EQUIPMENT
OPERATION
Only attempt to resolve alerts and errors detected by the device if you are fully familiar with the
safety-related applications and the non-safety-related applications as well as the hardware used
to operate your machine/process.
Failure to follow these instructions can result in death, serious injury, or equipment damage.
Topic Page
Diagnostics via LEDs 76
Diagnostics via Status Output Z1 79
