Diagnostics
HR9Z-B2192 8/2020 81
0010110101 Input S12 is expected to
change its state. In the
case of a configuration
with antivalent inputs,
inputs S12 and S13 are
expected to change their
states.
- S
0010111100 Input S22 is expected to
change its state. In the
case of a configuration
with antivalent inputs,
inputs S22 and S23 are
expected to change their
states.
- S
0010101011 Waiting for startup test. - S
0010101010 Waiting for rising edge
for automatic/manual
start or monitored start.
- S
0010101110 Start input activated.
Waiting for falling edge
for monitored start.
- S
0010101111 Device in operating state
Run:Outputs Energized,
safety-related outputs
activated.
- S
Bit sequence Description Correctives
Type
(1)
(1) Type of message: E = Error detected, A = Alert, S = Status information
