Note: Certain instructions can be programmed in a series after a timer instruction in WindLDR. These instructions are not automatically connected
to the right power rail as shown in the above ladder diagram. (Refer to the below diagram.)
For details, see "Timer Circuit" on page 4-9.
I0000
Q0000
I0001
T000
TML
4
T000
