A-8 FC6A S ERIES MICROS MART L ADDER P ROGRAMMING M ANUAL FC9Y-B1726
Instruction Size (Bytes)
The byte quantities for basic and advanced instructions are listed below.
Basic
Instruction
Used Data Size (Bytes)
All-in-One CPU Module/
CAN J1939 All-in-One CPU Module
Plus CPU Module
When Using Bits
Specified in Data
Registers
When Using Bit
Devices
When Using Bits
Specified in Data
Registers
When Using Bit
Devices
LOD 128128
LODN 12 12 12 12
OUT 8888
OUTN8888
SET, RST8888
AND 128128
ANDN 12 12 12 12
OR 128128
ORN 12121212
AND LOD ― 8 ― 8
OR LOD ― 8 ― 8
BPS ― 4 ― 4
BRD ― 4 ― 4
BPP ― 4 ― 4
TML ― 12 ― 12-16
TIM ― 12 ― 12-16
TMH ― 12 ― 12-16
TMS ― 12 ― 12-16
TMLO ― 12 ― 12-16
TIMO ― 12 ― 12-16
TMHO ― 12 ― 12-16
TMSO ― 12 ― 12-16
CNT ― 12 ― 12-16
CDP ― 12 ― 12-16
CUD ― 12 ― 12-16
CNTD ― 12 ― 12
-16
CDPD ― 12 ― 12-16
CUDD ― 12 ― 12-16
CC= ― 12 ― 12-16
CC>= ― 12 ― 12-16
DC= ― 12-16 ― 12-24
DC>= ― 12-16 ― 12-24
SFR ― 12 ― 12
SFRN ― 12 ― 12
SOTU ― 8 ― 8
SOTD ― 8 ― 8
MCS ― 4 ― 4
MCR ― 4 ― 4
JMP ― 12 ― 12
JEND ― 4 ― 4
END ― 4 ― 4
