11: W EEK P ROGRAMMER I NSTRUCTIONS
11-30 FC6A S ERIES MICROS MART L ADDER P ROGRAMMING M ANUAL FC9Y-B1726
[To turn on output Q0 on the last day of every month between 2013 and 2020]
Parameter tab
Configure the tab as shown above and set D1 to Q0.
ON date : 2013/**/end of month
OFF date : 2020/**/end of month
+ 1 day
Yearly : ON
Monthly : ON
ON
OFF
January February March April
31st 1st 28th/29th 1st 31st 1st 30th 1st
D1
Q0
S2YEAR S1 S3
1
M8125
