S1+22 Alarm 3 action
Set the Alarm 3 action type.
0: No Alarm Action
1: Upper Limit Alarm
2: Lower Limit Alarm
3: Upper/Lower Limit Alarm
4: Upper/Lower Limit Range Alarm
5: Process High Alarm
6: Process Low Alarm
7: Upper Limit Alarm with Standby
8: Lower Limit Alarm with Standby
9: Upper/Lower Limit Alarm with Standby
Operates as 0 (No Alarm Action) for value other than those listed above.
R/W
S1+23 Alarm 3 value
Set the value that will be the trigger condition for the Alarm 3 action.
For details, see "Alarm 3 value (S1+23)" on page 19-20.
R/W
S1+24 Alarm 3 hysteresis
Set the range from the alarm action point to when the alarm output changes
from ON to OFF.
Set a value that satisfies the following conditions in the range of 1 to 65,535
(0.1 to 6,553.5 (°C/°F), 1 to 65,535 (voltage/current input)).
R/W
• When Alarm 3 action is set to Upper/Lower Limit Alarm or Upper/
Lower Limit Alarm with Standby
1 ≤ Alarm 3 hysteresis < Alarm 3 value
• When Alarm 3 action is not set to Upper/Lower Limit Alarm or Upper/
Lower Limit Alarm with Standby
1 ≤ Alarm 3 hysteresis ≤ 65,535
When 0, hysteresis operates as 1 (0.1 (°C/°F) or 1 (voltage/current input)).
S1+25 Alarm 3 delay time
Set the time until the alarm output is turned ON after the condition to turn
the alarm output ON is satisfied.
Set as 0 (delay time disabled) or in the range of 1 to 10,000 (1 to 10,000
seconds).
When 10,001 or higher, delay time operates as 10,000 seconds.
R/W
S1+26 Alarm 4 action
Set the Alarm 4 action type.
The setting details are the same as Alarm 3 action (S1+22).
R/W
S1+27 Alarm 4 value
Set the value that will be the trigger condition for the Alarm 4 action.
The setting details are the same as Alarm 3 value (S1+23).
R/W
S1+28 Alarm 4 hysteresis
Set the range from the alarm action point to when the alarm output changes
from ON to OFF.
The setting details are the same as Alarm 3 hysteresis (S1+24).
R/W
S1+29 Alarm 4 delay time
Set the time until the alarm output is turned ON after the condition to turn
the alarm output ON is satisfied.
The setting details are the same as Alarm 3 delay time (S1+25).
R/W
S1+30 Alarm 5 action
Set the Alarm 5 action type.
The setting details are the same as Alarm 3 action (S1+22).
R/W
S1+31 Alarm 5 value
Set the value that will be the trigger condition for the Alarm 5 action.
The setting details are the same as Alarm 3 value (S1+23).
R/W
S1+32 Alarm 5 hysteresis
Set the range from the alarm action point to when the alarm output changes
from ON to OFF.
The setting details are the same as Alarm 3 hysteresis (S1+24).
R/W
S1+33 Alarm 5 delay time
Set the time until the alarm output is turned ON after the condition to turn
the alarm output ON is satisfied.
The setting details are the same as Alarm 3 delay time (S1+25).
R/W
S1+34 Alarm 6 action
Set the Alarm 6 action type.
The setting details are the same as Alarm 3 action (S1+22).
R/W
S1+35 Alarm 6 value
Set the value that will be the trigger condition for the Alarm 6 action.
The setting details are the same as Alarm 3 value (S1+23).
R/W
S1+36 Alarm 6 hysteresis
Set the range from the alarm action point to when the alarm output changes
from ON to OFF.
The setting details are the same as Alarm 3 hysteresis (S1+24).
R/W
S1+37 Alarm 6 delay time
Set the time until the alarm output is turned ON after the condition to turn
the alarm output ON is satisfied.
The setting details are the same as Alarm 3 delay time (S1+25).
R/W
S1+38
S1+39
— Reserved — — —
Storage
Destination
Function Setting Details R/W
