FC6A S
ERIES
MICROS
MART
L
ADDER
P
ROGRAMMING
M
ANUAL
FC9Y-B1726 26-7
26: S
CRIPT
Script Manager
In the Script Manager dialog box, you can add scripts created in the Script Editor dialog box or delete registered scripts.
1. List of scripts
Shows the list of registered scripts.
2. Script
Shows the contents of the script selected in the List of scripts.
3. Add
Click this button to display the Script Editor dialog box in order to create and add a script.
For details, see "Script Editor" on page 26-8.
4. Edit
Click this button to open the Script Editor dialog box in order to edit the script selected in the List of scripts.
For details, see "Script Editor" on page 26-8.
5. Delete
Click this button to delete the script selected in the List of scripts.
6. Select
This can only be used when Script Manager has been opened from the SCRPT instruction dialog box.
Select a script in the list of scripts and click this button to enter the selected script ID in S1 on the dialog box.
7. Close
Click this button to close Script Manager.
Note: If you click Close when the list of scripts was modified, a save confirmation message is displayed. Click Yes on the confirmation message to
save the changes. Click No to discard the changes and close Script Manager.
Script ID: Shows the script ID of the registered scripts (1 to 255).
Error: Shows OK if the registered script has no errors. Shows NG if there are any errors.
Script name: Shows the name of the registered scripts.
Used: Shows whether or not the registered scripts are used in this project.
To Next Page
