IDEC MICROSmart FC6A-C24R1CE

A PPENDIX
A-2 FC6A S ERIES MICROS MART L ADDER P ROGRAMMING M ANUAL FC9Y-B1726
IMOV, IMOVN (D) D+D→D+D 18.8 9.4
IMOV (F) ― 13.9 7.00
MOVC ―― ―
BMOV D→D 16.1 + 1.2n 8.1 + 0.6n
IBMV, IBMVN
M+D→M+D 13.4 6.7
D+D→D+D 13.4 6.7
NSET (W, I) D→D 2.28 + 2.2n 1.14 +1.1n
NSET (D, L) D→D 2.2 + 12.6n 1.1 + 6.3n
NSET (F) D→D 2.2 + 12.6n 1.1 + 6.3n
NRS (W, I) D, D→D 5.84 + 0.64n 2.92 + 0.32n
NRS (D, L) D, D→D 11.1 + 5.7n 5.6 + 2.9n
NRS (F) D, D→D 11.0 + 5.8n 5.5 + 2.9n
XCHG (W) D⇔D 5.32 2.66
XCHG (D) D⇔D 26.0 13.0
TCCST (W) D→T 4.68 2.34
TCCST (D) D→T 15.0 7.5
CMP (=, <>, <, >, <=, >=) (W, I) D⇔D→M 27.6 13.8
CMP (=, <>, <, >, <=, >=) (D, L) D⇔D→M 38.0 19.0
CMP (=, <>, <, >, <=, >=) (F) D⇔D→M 38.2 19.1
ICMP (>=) D⇔D⇔D→M 29.0 14.5
ICMP (D, L, F) D⇔D⇔D→M 44.6 22.3
LC (=, <>,<, >, <=, >=) (W, I) D⇔D 4.84 2.42
LC (=, <>,<, >, <=, >=) (D, L) D⇔D 15.2 7.6
LC (=, <>,<, >, <=, >=) (F) D⇔D 15.3 7.7
ADD (W, I)
M+M→D 11.6 5.8
D+D→D 11.7 5.9
ADD (D, L)
M+M→D 27.2 13.6
D+D→D 27.2 13.6
ADD (F) D+D→D 27.8 13.9
SUB (W, I)
M-M→D 11.6 5.8
D-D→D 11.7 5.9
SUB (D, L)
M-M→D 27.2 13.6
D-D→D 27.2 13.6
SUB (F) D-D→D 27.4 13.7
MUL (W, I)
M×M→D 11.2 5.6
D×D→D 11.3 5.7
MUL (D, L)
M×M→D 27.2 13.6
D×D→D 27.2 13.6
MUL (F) D×D→D 27.4 13.7
DIV (W, I)
M÷M→D7.03.5
D÷D→D 6.96 3.48
DIV (D, L)
M÷M→D 28.0 14.0
D÷D→D 28.0 14.0
DIV (F) D÷D→D 28.0 14.0
INC (W, I) ― 8.92 4.46
INC (D, L) ― 19.3 9.65
DEC (W, I) ― 8.92 4.46
DEC (D, L) ― 19.2 9.6
ROOT (W) 6.24 3.12
ROOT (D) 18.0 9.0
ROOT (F) 19.4 9.7
SUM (W, I) D, D→D 11.3 + 0.8n 5.7 + 0.4n
SUM (D, L) D, D→D 16.6 + 6.0n 8.3 + 3.0n
SUM (F) D, D→D 16.8 + 7.0n 8.4 + 3.5n
Instruction Device and Condition
Execution Time (μs)
All-in-One CPU Module/
CAN J1939 All-in-One CPU
Module
Plus CPU Module
D →D
D →D
D →D
