IDEC MICROSmart FC6A-C24R1CE Ladder Programming Manual

FC6A S ERIES MICROS MART L ADDER P ROGRAMMING M ANUAL FC9Y-B1726 3-15
3: I NSTRUCTIONS R EFERENCE
■ Advanced Instructions
OR LOD —
BPS, BRD, BPP —
TML, TIM, TMH, TIMS,
TMLO, TIMO, TMHO, TIMSO
— Indirect addressing is not supported because unique numbers are allocated.
CNT, CDP, CUD,
CNTD, CDPD, CUDD
— Indirect addressing is not supported because unique numbers are allocated.
CC=, CC>=, DC=, DC>= —
SFR, SFRN —
SOTU, SOTD —
MCS, MCR —
JMP, JEND —
END —
Instruction
Indirect
Addressing
Comments
NOP —
MOV, MOVN X
IMOV, IMOVN —
MOVC X
BMOV X
IBMV, IBMVN —
NSET X
NRS X
XCHG X
TCCST X
CMP=, CMP<>, CMP<,
CMP>, CMP<=, CMP>=
X
ICMP>= X
LC=, LC<>, LC<,
LC>, LC<=, LC>=
X
ADD X
SUB X
MUL X
DIV X
INC X
DEC X
ROOT X
SUM X
RNDM X
ANDW X
ORW X
XORW X
SFTL, SFTR X
BCDLS X
WSFT X
ROTL, ROTR X
HTOB X
BTOH X
HTOA X
ATOH X
BTOA X
ATOB X
ENCO —
DECO —
BCNT X
Command
Indirect
Addressing
Comments
