i-MARK 2, i-MARK 3 without mains connectors
7.2.4 DC Power Supply
Place a fuse of 1 A slow blow in the supply cabling of every i-MARK2/3.
7.2.5 Mains Power Supply (i-MARK 2 only)
The compact unit i-MARK 2 is available with an internal power supply to operate at a mains voltage of
100 - 240 VAC (Europe only).
Important Safety Note
Mounting of the mains wiring must be done by skilled staff.
In order to connect the mains wiring the front cover needs to be removed.
Keep the dismantled part of the mains wiring as short as possible.
Keep the yellow-green wire (protective earth, PE) 2 cm longer.
Equip the wire ends with wire end sleeves.
