i-MARK 2 / i-MARK 3
USER MANUAL
VISIBILITY DELIVERED. PAGE 49 OF 55
1 X X X
2 X X X
3 X X X X X
4 X X X X X
5 X X X X X
6 X X X X X
7 X X X
8 X X X
Slot configuration table.
Slot number 1 2 3 4 5 6 7 8 9 10 11 12
Marker 1 T T T
Marker 2 T T T
Marker 3 T T T
Marker 4 T T T
Marker 5 T T T
Marker 6 T T T
Marker 7 T T T
Marker 8 T T T
8.7 Checking the Installation
After completing the installation the operation must be systematically checked. The installation check
can be divided into three sections:
Visual test
Basic operational check
Detailed operational check.
If the basic check of the operational behavior is to be carried out using a (portable) PC a final check
via the intended user control system should also be carried out.
8.8 Status Display (LEDs)
LOOP This LED lights green during sending a LF telegram (about 20 ms). In case of a loop
error (loop broken or the set point of the loop current couldn’t be reached) the LED
flashes in a warning color when sending a LF telegram.
RUN This LED blinks green, indicating the system is running normal.
