17
During cutting, the gap between the blade tips (in the transverse direction) must not be
exceeded,otherwisethebladeisindangerofbreaking:
ATTENTION!
Wherepossible,avoidcuttingthroughhigh-strengthpartsofthevehiclebody
(e.g. side impact protection).This may result in damage to the blades or to
increasedwearandtear!
eDRAULIC cutting device max. gap at the blade tips
[mm] / [in.]
SC 258 E2 3 / 0.12
SC 358 E2 3 / 0.12
SC 757 E2 3 / 0.12
SC 758 E2 3 / 0.12
Cutting with SC 358 E2, SC 757 E2 and SC 758 E2
ThespreadertipofSC358E2,SC757E2andSC758E2canberemoved.Thisprevents
thematerialfrombecomingstuckbetweenthespreadertips,hinderingthecuttingprocess.
Removing the spreader tip
Step 1:
Toremovethespreadertips,rstpushoutbolt“A”alittle,usingangeroranobject.Afair
amountofforceneedstobeappliedinitially,asthebolthasaballcatchtopreventitfrom
fallingoutunintentionally.
3.
2.
1.
A
