38
11.2 Noise emission (based on standard EN ISO 3744)
Device type
SC 258 E2,
SC 358 E2,
SC 757 E2,
SC 758 E2
Battery type used for device Lithium/ion
Idling
(measuredatadistanceof1m,accordingtoEN)
[dB(A)] 74
Full load
(measuredatadistanceof1m,accordingtoEN)
[dB(A)] 77
Idling
(measuredatadistanceof4m,accordingtoNFPA)
[dB(A)] 69
Full load
(measuredatadistanceof4m,accordingtoNFPA)
[dB(A)] 71
11.3 Operating and storage temperature ranges
Operating temperature [°C]/[°F] -20 … +55 -4 … +131
Storage temperature
(devicenotinoperation)
[°C]/[°F] -30 … +60 -22 … +140
11.4 Oscillation / vibration
Thetotaloscillationvalue/vibrationvaluetowhichtheupperlimbsareexposed,isusually
below2.5m/s².
Highervaluesmaybemeasuredforshortperiodsasaresultofinteractionwiththematerials
tobeprocessed.
(The oscillations / vibrations were determined in accordance with DIN EN ISO 20643.)
11.5 Torques for central bolts
Device type SC 258 E2 SC 358 E2 SC 757 E2 SC 758 E2
Pivot bolt
M24x1,5 M28x1,5 M32x1,5 M32x1,5
Wrench size
[mm] 36 38 46 46
[in.] 1.42 1.50 1.81 1.81
Torque
[Nm] 130 +10 130 +10 160 +10
150+10
[lbf∙in] 1151 + 90 1151 + 90 1416 + 90 1328 + 90
