IDTECK iPass IP100R - Wiring Color Table

Quick Installation Guide
Jun. 2011 Copyright © IDTECK Co., Ltd.
5. WIRING COLOR TABLE
I/O PORT NAME
SIGNAL NAME
COLOR CODED
2PIN
(J1)
Main Power(+12V)
DC +12V
Red
Power Ground
GND
Black
10PIN
(J2)
Door Relay(NC)
NC(1)
Blue with White Stripe
Door Relay(COM)
COM(1)
Gray with Red Stripe
Door Relay(NO)
NO(1)
White with Red Stripe
Alarm Relay(NC)
NC(2)
Purple with White Stripe
Alarm Relay(COM)
COM(2)
White
Alarm Relay(NO)
NO(2)
Purple
Exit Button
EXIT
Orange
Door Sensor
CONTACT
Yellow with Red Stripe
Aux Input 1
INPUT1
Green
Aux Input 2
INPUT2
Green with White Stripe
7PIN
(J3)
Wiegand Data0
DATA0
Pink
Wiegand Data1
DATA1
Cyan
TTL Output
TTL1/D0
Orange with White
Chime Bell Output
CHI/D1
Brown with White Stripe
Aux Input 3
INPUT3
Green with Red Stripe
RESERVED
Blue with Red Stripe
RESERVED
Yellow with White Stripe
3PIN
(CON2)
RS232-TX
TXD
Black with White Stripe
RS232-RX
RXD
Red with White Stripe
Ground
GND
Black
