Virtual Output Description/Details
Forced Door
This output activates if the door position
switch is opened without entering a valid
user code or using the REX feature.
OUT2, OUT3, OUT4,
OUT5
These four independently controlled outputs
are activated by user codes programmed to
activate multiple outputs and the REX
function. See programming commands 59
and 49 in the Programming section.
Duress
The duress output is activated when a
duress user enters their code. See Duress
User in the Programming section.
Panic
Panicisactivatedbypressingthe* and #
keys at the same time. This is used in case
of emergency to activate an auxiliary device
andshouldnotbeusedtogainaccess.
Keypad Active
The Keypad Active output is activated when
any key is pressed. Do not use this output
to gain access.
7.2.2 Audio Alerts
Audio Alerts are produced by the local sounder on the keypad
and can be used as a local propped door alarm or forced door
alarm to free up the other relays for other functions.
• Alert #1 is a constant quick beep (¼ second on and ¼ sec-
ond off).
• Alert #2 is a short beep (100 ms) every two seconds.
• Alert #1 takes priority over Alert #2.
7.2.3 Programming REX Outputs
49#outputlist#0#**
(Use this command to program which outputs the REX operates.
1=LOCK,2=OUT2,3=OUT3,
4=OUT4,and5=OUT4.)
IEI 212eM/242eM Standalone Installation/Programming Manual
18 Document # 6174000, Rev. 1.1
