2. Specifications
Parameter Range/Description
Voltage
10-30 VDC,
12-24 VAC
Current
46mA@10VDC,
68mA@30VDC,
49mA@12VAC, and 60mA@24VAC
Add 20 mA for each auxillary relay
Environment Indoor and Outdoor
Temperature Tolerance -20°F to 130°F (-28°C to 54°C)
Dimensions 4.5" H x 2.75" W x 0.60" D
Main Relay (Form C)
Contact Rating: 2A @
30VAC/DC
Auxillary Relay (Form C)
Contact Rating: 1A @
24V AC/DC
REX Input Normally Open Dry Contact
Door Position Input Normally Closed Dry Contact
LEDs
Bi-Color Red/Green
Yellow
212eM/242eM Default Settings
Parameter Default Setting
Master Code 1234
Lock Output Relay 1 (Main Relay)
Alarm Shunt Relay 2
Propped Door Relay 3
Forced Door Relay 4
Audio Alerts Not Assigned
REX Triggers Lock Output
REX Operation
Always Triggers (regardless of
Door Loop)
Error Lockout Enabled
Error Lockout Threshold 3 Attempts
Error Lockout Duration 10 Seconds
Lock Output Time 5 Seconds
Propped Door Time 30 Seconds
Forced Door Time 10 Seconds
Visual Keypress Feedback Enabled
Audio Keypress Feedback Enabled
Auto-Entry Enabled
User Lockout Enabled
IEI 212eM/242eM Standalone Installation/Programming Manual
4 Document # 6174000, Rev. 1.1
