IEI Technology ROCKY-538TXV User Manual

11
 Dual / Single CPU Voltage setting:
Vcore & VIO JP10 JP11 JP6 JP7
Pentium®
(P54C)
SHORT SHORT OPEN OPEN
Pentium®
MMX
AMD K6
Cyrix 6x86MX
Dual Voltage
OPEN OPEN SHORT SHORT
Intel Low-
Power
Embedded
Processor
OPEN OPEN OPEN OPEN
 Cyrix 6x86MX PR Rating Table
( Vcore : 2.9V,dual voltage )
PR Rating Bus MHz
CPU Core
MHz
Clock
Multiplier
6x86MX-PR133 50 100 2x
6x86MX-PR133* 55 110 2x
6x86MX-PR150 60 120 2x
6x86MX-PR150 50 125 2.5x
6x86MX-PR166 66 133 2x
6x86MX-PR166 55 138 2.5x
6x86MX-PR166 50 150 3x
6x86MX-PR166 60 150 2.5x
6x86MX-PR200 55 165 3x
6x86MX-PR200 66 166 2.5x
6x86MX-PR200 60 180 3x
6x86MX-PR233 66 200 3x
6x86MX-PR266 66 233 3.5x
 AMD K6 MMX Rating Table, dual voltage
Product Name Core
Freq
Vcore Bus MHz Multiplier
K6-233 model 6 233MHz
3.2V 66 3.5x
K6-200 model 6 200MHz
2.9V 66 3x
K6-166 model 6 166MHz
2.9V 66 2.5x
K6-300 model 7 300MHz
2.2V 66 4.5x
K6-266 model 7 266MHz
2.2V 66 4x
K6-233 model 7 233MHz
2.2V 66 3.5x
