20
3.13 5V Standby Connector for ATX power supply
•
ATX Power Supply 20-pin power connector
1 12V 2 5V
3 5V standby 4 5V
5 PW-0K 6 -5V
7 Ground 8 Ground
9 5V 10 Ground
11 Ground 12 Ground
13 5V 14 Suspend Control
15 Ground 16 Ground
17 3.3V 18 -12V
19 3.3V 20 3.3V
