Electrical connection
►Disconnectpowerbeforeconnecting
theproximityswitch;connection:
→fig.5).






• Forcableslongerthan30mandwiresgreaterthan0.5mm²thecableshould
belaidseparatelyfromsourcesofinterference(atadistanceofabout50cm)
or a screened cable should be used.
• Connecttheloadbeforeapplyingtheoperatingvoltage.
• Observethevaluesforcurrentratingandminimumloadcurrent.
• Ifcapacitiveloadsareused,ensurethatthepeakcurrentratingisnot
exceeded.
