IFM Electronic Efector 100 - Connecting Loads

4
►Donotconnectloadsoflowresistance(e.g.lamps)directlytothesensor.
Switchtheseloadsviaarelay(→fig.6):




►ForinductiveloadsaRCcircuit
should be connected in parallel to the
load(→fig.7).



►Aloadwhichistoolowfor2-wire
sensors may lead to malfunction.
In such a case a resistor should be
connected in parallel to the load
(→fig.8).



• Forseriesconnectionconsiderthevoltagedropofeachunit.
