Adjustment of the valve positions of valves with 3 operating positions
25
1
Press the Pos.
pushbutton for min. 2s.
All LEDs flash 2x simultaneously.
The unit is in the programming
mode.Then only the LED "closed" is lit.
The unit is now ready for the adjustment
of the closed position.
2
Put the valve into the
closed Pos. and press
the Teach button.
The LED "closed" goes out
and the LED "seat" lights.
The unit has stored the closed position
and is now ready for the adjustment
of the position seat lift (seat).
3
Put the valve into the
position seat lift and
press the Teach button.
The LED "seat" goes out
and the LED "open" lights.
The unit has stored the position seat lift
and is now ready for the adjustment
of the open position.
4
Put the valve into the
open position and
press the Teach button.
The LED "open" goes out
and the LED "closed" lights again.
The unit has now stored all positions.
5
Press the Pos.
pushbutton for
min. 5s.
After 5s the LED
"open" flashes at
about 2Hz.
After releasing all stored measured values
are checked. If no errors are detected all
LEDs flash 2x simultaneously. The unit
automatically quits the programming
mode and immediately passes into the
operating mode.
If, however, an error is found during the
check the LED "closed" flashes at about
8Hz. Acknowledge the error message by
pressing the Pos. button and repeat the
adjustment.
