7.2.2 Pictograms and main navigation
Quicksetup (Summary of the menu points required for a basic
configuration)
• Project all
Projection adaptation for AS-i master 1 and AS-i master 2 (only AC1402)
• Operating mode
Selection of the operating modes for
- AS-i master 1,
- AS-i master 2 (only AC1402),
- system (gateway, manual)
• fieldbus
- display / modify the parameters of the Profinet interface
- IP address
- Subnet mask
- Gateway address
• Configuration interface
- Display / modify the parameters of the Ethernet configuration interface
- DHCP
- IP address
- Subnet mask
- Gateway address
• Addressing 1
- Slave overview AS-i line 1 (with the option to change AS-i addresses)
• Addressing 2
- Slave overview AS-i line 2 (with the option to change AS-i addresses)
AS-i 1
• AS-i master settings
• AS-i diagnosis
• AS-i slaves
AS-i 2
• AS-i master settings
• AS-i diagnosis
• AS-i slaves
System
• Information
• Settings
• Diagnostics
