5
UK
The installation and connection must comply with the applicable national and
international standards� Responsibility lies with the person installing the device�
This is a class A product� The unit may cause radio interference in domestic areas� In
this case it can be necessary for the user to take appropriate measures�
2.3 Tampering with the device
Tampering with the device is not allowed and will lead to an exclusion of liability
and warranty� Tampering with the device can affect the safety of operators and
machinery�
► Do not open the device�
► Do not insert any objects into the device�
► Prevent metal foreign bodies from penetrating�
3 Functions and features
The AS-i Profinet gateway includes one (AC1401) or two (AC1402) AS-i masters,
one WEB server and a Profinet interface with 2-port switch�
• It controls the exchange of data to the sensor / actuator level�
• It communicates with the superior control level via Profinet�
• It visualises sensor/actuator data on the integrated WEB server�
• It allows device configuration via the WEB server�
3.1 Configuration interface X3
• 10 Mbps and 100 Mbps
• TCP/IP - Transport Control Protocol/ Internet Protocol
• UDP - User Datagram Protocol
• IT functionality: HTTP server
• RJ45, Twisted-Pair
3.2 Fieldbus interface X6 and X7
• Profinet RT device class B incl� MRP protocol (Media Redundancy Protocol)
• 100 Mbps
3.3 Electrical supply
• the unit can be supplied either from 24 V (AUX) or from AS-i
• AS-i power 24 V compatible
