CR711S Connector A / input characteristics
Control systems
Digital input (B
L/H
)
Input resistance 10 k Ω
Input frequency < 330 Hz
Switch-on level
> 0�7 VBB
30
Switch-off level < 0�3 VBB
30
Accuracy B
L/H
± 1 %
Range diagnostics confi gurable minimum and maximum values
for the measuring range to detect short circuit
to VBB and short circuit to GND / wire break
Range diagnostics min - max� 1 V / 0�95 VBB
30
(default)
Connector A:
IN0400...0401
IN0900...0901
Resolution 12 bits
Input frequency < 330 Hz
Range diagnostics confi gurable minimum and maximum values
for the measuring range to detect short circuit
to VBB and short circuit to GND / wire break
Digital/ resistor inputs
(IN RESISTOR-A)
Digital input (B
L
)
Input resistance 10 k Ω
Switch-on level
> 0�7 VBB
30
Switch-off level < 0�3 VBB
30
Accuracy B
L
± 1 %
Range diagnostics min - max� 1 V / 0�95 VBB
30
(default)
Resistor input (R)
Measuring current < 2�0 mA
Measuring range 0.016...30 kΩ
Accuracy ± 2% FS: 0.016...3 kΩ
± 5 % FS: 3...15 kΩ
± 10 % FS: 15...30 kΩ
Range diagnostics min - max� 0 Ω / 31 kΩ
(default)
Connector A:
IN0300... 0301
IN0800... 0801
Resolution 12 bits
Input frequency < 330 Hz
Impedance ≤ 3.2 k Ω
Range diagnostics confi gurable minimum and maximum values
for the measuring range to detect short circuit
to VBB and short circuit to GND / wire break
Digital inputs 2-wire sensor
(IN DIGITAL-B)
Digital input (B
L
)
Input resistance 3.2 k Ω
Switch-on level
> 0�7 VBB
30
Switch-off level < 0�3 VBB
30
Accuracy B
L
± 1 %
Range diagnostics min - max� 1 V / 0�95 VBB
30
(default)
Observe the notes on the confi guration of the inputs/outputs!
(Programming manual "ecomatController CR711S")
