ecomatController CR710S/CR711S
37
ifm electronic gmbh ● Friedrichstraße 1 ● 45128 Essen We reserve the right to make technical alterations without prior notice! 22 Nov� 2017CR711S / page 7
CR711S Connector A / input characteristics
Control systems
Abbreviations A
B
H
B
L
FRQ
L/H
PWM
H
PWM
L
PWM
I
R
VBB
0���2
VBB
30
analogue
binary high side (CSO)
binary low side (CSI)
frequency/pulse inputs confi gurable low side (CSI) / high side (CSO)
pulse-width modulation high side (CSO)
pulse-width modulation low side (CSI)
pulse-width modulation current-controlled
resistance input
supply output group via semiconductor switch
supply sensors/module
