User manual Jamajka W, Marta W www.igloo.pl
Fig.1 Construction of “Jamajka” device 13
Fig.2 Construction of “Marta” device 13
Fig.3 Fixing the hook in the frame 15
Fig.4 Hook height regulation 15
Fig.5 Assembly of glass elements 15
Fig.6 Control panel 16
Fig.7 Hygrostat 17
Fig.8 Disassembly of the front glass 17
Fig.9 Manner of assembling/pulling out of the blow-in and suction
18
Fig.10 Condenser cleaning 18
Fig.11 Changing the fl uorescent lamp 19
Fig.12 Data plate 20
Fig.13 „Igloo” thermostat control panel 21
Fig.14 „Carel” thermostat control panel 22
1. UNLOADING
The device should be transported in vertical position, and it should be properly secured and packed. The manufacturer
ships the device on a special wooden platform, secured with cardboard angle sections and foil.
2. PROPERTIES OF THE DEVICE
2.1. Purpose
“Jamajka W” and “Marta W” display cabinets are universal cooling devices aimed to display and short-term storage of
confectionery goods: cakes, cookies, desserts, etc. in temperature between +5ºC and +15ºC with ambient temperature
between +15ºC and +25ºC and relative air humidity not exceeding 60%.
2.2. Description of the device
“Jamajka W” and “Marta W” have dynamic cooling. All types of devices are equipped with automatic condensate evapora-
tion and automatic defrosting. They are also furnished with electronic thermostat optionally cooperating with temperature
recording module enabling to record and signal too low and too high temperature within the device. They are adjusted
to be connected in sequences and may be supplied with internal and external aggregate (“-mod C”). Within the range of
temperatures between +10ºC/+15ºC it is possible to control air humidity within display cabinets, between 30 and 80%.
Glass shelves fi xed on the frame make the exhibitive part of display cabinets. In case of “Jamajka” it can be possible
to change the height and angle of the shelves. Our devices are made according to modern technologies and have all
certifi cates required by law.
This sign signifi es information of particular meaning for user security and for proper device
exploitation.
Contents List of Figures
List of tables
Table 1 Technical data 14
User manual
JAMAJKA W, MARTA W
1. UNLOADING 12
2. PROPERTIES OF THE DEVICE 12
2.1. Purpose 12
2.2. Description of the device 12
2.3. Technical data 14
3. PREPARING THE DEVICE FOR EXPLOITATION 14
3.1. Requirements concerning the place of installation 14
3.2. Connection and actuation 14
4. EXPLOITATION 16
4.1. Temperature regulation 16
4.2. Humidity regulation 17
5. MAINTENANCE 17
5.1. Cleaning and maintenance 17
6. SERVICE 19
6.1. Fault identifi cation and repair 19
6.2. Service 20
7. THERMOSTAT SERVICE 21
7.1. „IGLOO” thermostat 21
7.2. „CAREL” thermostat 22
