IHI 15VX - BACKHOE OPERATION

2 – 15
OPERATION
2-8-1 BACKHOE OPERATION
Shown lever pattern A (ISO) type operations.
OPERATIONS DIRECTION OF LEVER DIRECTTON OF MACHINE
BOOM
BUCKET
ARM
SWING
When leaving the operator’s seat, stop the engine, lower the bucket and the
blade on the ground.

Lower
Operating
lever (R.H.)

Raise
Operating
lever (L.H.)

Out

In
Operating
lever (L.H.)
Swing
right

Swing
left


Out

In

Lower

Raise

Swing
right

Swing
left

Dump
Operating
lever (R.H.)

Dig

Dump

Dig
