Error Codes
The control module has the ability to detect problems with the
valve kit system and will initiate error codes when they occur.
The error codes listed below will guide you to solving trouble-
shooting issues.
Ignition Safety Error: One short beep every one second.
Cause: Pilot did not light within the trial period of 50-60 seconds
therefore step motor will turn gas valve to OFF position.
Corrective Action: Press OFF button to clear. Wait 30 seconds and
try again.
Recycle Safety Error: Two short beeps every one second.
Cause: 1. Pilot automatically lights and drops out 3-times within
2-minutes causes step motor to turn gas valve to OFF position. 2.
Someone has pressed the ON/OFF button 6-times within 2-minutes
causing the step motor to turn gas valve to OFF position.
Corrective Action: Press OFF button to clear. After 5-minutes the
beeping will stop then retry.
ERROR CODE TROUBLESHOOTING
OPTIONAL ACCESSORIES
PRODUCT REFERENCE INFORMATION
Cat. No. Model# Description
F3502 LPK 1 LP Conversion kit for 36-inch outdoor fireplace
F3503 LPK 2 LP Conversion kit for 48-inch outdoor fireplace
F3504 LPK 3 LP Conversion kit for 60-inch outdoor fireplace
F3505 LPK 4 LP Conversion kit for 72-inch outdoor fireplace
F3507 GLO-BLACK Black Onyx Glass Media, 5lb
F3508 GLO-CRYSTAL Diamond Crystal Glass Media, 5lb
F3509 GLO-LT BLUE Sapphire Blue Glass Media, 5lb
Remote Control Kit
Cat. No. Model# Description
F2687 EF-BRCK
Remote Control, Manual ON/OFF operation,
Off / Continuous pilot feature
ON
OFF
HI
LO
PILOT
Continuous
Sensor Safety Error: Four short beeps every one second (constant
beeping).
Cause: Pilot flame sensor voltage too high, ground circuit not prop-
erly connected, pilot ground wire loose or not connected, or motor
not plugged into control module; therefore, step motor will turn gas
valve to OFF position.
Corrective Action: Press OFF button to clear. Wait 30-seconds to
thermocouple to cool down. If persist, then check other possible
causes and retry.
Thermal Safety: Four short beeps every two seconds.
Cause: System has overheated and exceeded 170°F internal tem-
perature limit and the step motor will turn gas to OFF.
Corrective Action: Internal temperature must cool down to below
160°F then press the OFF button to clear and retry.
Communication Safety: One short beep every four seconds.
Cause: Transmitter and module are not communicating properly.
Could be related to distance greater than 20-feet away from each
other or weak/dead batteries in one or the other.
Corrective Action: Module must receive a signal from transmitter.
Product Reference Information
Linear Electronic VF Outdoor Fireplaces
Cat. No. Model Description
F3442 BarcelonaLights36ZEN Astria
®
, 36”, Natural Gas
F3443 BarcelonaLights48ZEN Astria, 48”, Natural Gas
F3444 BarcelonaLights60ZEN Astria, 60”, Natural Gas
F3445 BarcelonaLights72ZEN Astria, 72”, Natural Gas
F3446 VRE4636ZEN Superior
®
, 36”, Natural Gas
F3447 VRE4648ZEN Superior, 48”, Natural Gas
F3448 VRE4660ZEN Superior, 60”, Natural Gas
F3449 VRE4672ZEN Superior, 72”, Natural Gas
