BURNER PAN ASSEMBLY
Pilot
(Hidden Underneath)
Burner
Tube
Ignition
Hole
FLAME HEIGHT
Figure 39 - Proper flame height
Proper flame height (Figure 39) should be at the top edge of glass windshield (peaking above at times) while on HI setting. The LO setting
will be at least half of the height of HI or maybe lower. There can be a variance in flame height between Natural gas and Liquid Propane
(LP) gas models.
FINAL PREPARATION
Continued
