SINGLE-SIDED FIREPLACE
DIMENSIONS, FRAMING
AND CLEARANCES SECTION
This fireplace comes with various boxes prepackaged inside the fireplace. Do not discard any boxes unless notes to
do so. Read the list below for the contents.
Component Parts Box Contents:
(1) RGB Control Assembly (includes switches and LED dimmer)
(1) 12VCD Adaptor (used for LED lighting)
(1) 7.5VCD Adaptor (used for valve system)
(2) Pilot Covers (used inside burner pan area)
(2) 6x12 Black Vents (used to ventilate enclosure)
(12) Black Screws, Nuts & Washers for 6x12 vents
(1) Installation manual for vent kit
(1) 24-inch LED wire harness
(1) 10-foot valve system (module) wire harness
(1) LED 10-foot controller wire harness
Windshield Parts Box Contents:
(2) Glass Windshields (inside firebox)
(4) LED Retainer Clips (2 for singled-sided; 4 for see-through fireplace)
(8) Glass Windshield Clips (4 for singled-sided; 8 for see-through fireplace)
(2) Stainless Steel Hoods (1 for singled-sided; 2 for see-through fireplace)
LED Assemblies Box Contents:
(1) LED Tray Assembly Left
(1) LED Tray Assembly Right
(4) LED Glass Retainer Clips & Pan Head Screws
(8) Windshield Clips & Pan Head Screws
Glass Media Box Contents:
(3-5) bags of diamond crystal media depending on model size (See Table 7 and Figure 33 on Page 24 for reference)
NOTE: Preparation for the LED lighting and the inlet gas line must be
planned before the fireplace is installed. See Page 5, Figure 1 for inlet
gasline and Page 15 for LED lighting.
SINGLE-SIDED FIREPLACE DIMENSIONS AND CLEARANCES
