OPERATING THE MONITOR 31
*
1
For use under the RS-232C control mode.
*
2
RS-232C can bring any mode out of the power saving status.
*
3
Only AV, YPbPr and HDMI(Video) inputs.
*
4
Only VGA and HDMI(PC) inputs.
*
5
Only VGA input.
*
6
For best results, use the Auto Adjust in conjunction with the adjustment pattern. See page 36 for
SCREEN ADJUSTMENTS.
*
7
Available for ProLite TH5565MIS only.
*
8
IP adress is displayed only when LAN is connected.
Adjustment Item Problem / Option Button to Press
Setting
Anti Image
Retention
Image Retention is turned off.
Automatically displays swift moving patterns every 1
second to prevent image retention on the screen.
OSD Info Box
OSD Info Box is turned off.
Switching signal inputs, or changing timing, the current
input source and resolution information will be displayed
on the screen.
On
Off
OSD
Rotation
On
Off
Landscape
Portrait
Portrait display
Landscape display
IR Out
IR Out is turned off.
To operating multiple monitors with one remote control.
Multiple monitors to connect using the IR cables.
On
Off
See your graphic card user guide for more information about
changing the resolution and refresh.
Date/Model Name/Serial Number/Operation Time/Software Version/
LAN Version/IP Address*
8
NOTE
Information
All Reset
Factory-preset data is restored.
Yes
No
Return to Menu.
Anti Image Retention
OSD Rotation
Landscape
On
IR Out
Opening Logo
On
Information
All Reset
Setting
Touch Feature
Off
Off
OSD Info Box
Off
Opening Logo
On
Off
iiyama Logo displayed when the monitor is turned on.
iiyama Logo does not display when the monitor is turned
on.
Touch Feature*
7
On
Off
Return to Menu.
Enable the touch function.
Display wall will be disabled to optimize touch
performance.
NOTE

Iiyama ProLite TH5565MIS Specifications

General

Panel life	- h
Pixel pitch	0.63 x 0.63 mm
Response time	12 ms
Display diagonal	55 \
Display brightness	400 cd/m²
Display technology	LED
Native aspect ratio	16:9
Vertical scan range	50 - 76 Hz
Horizontal scan range	30 - 83 kHz
Supported video modes	1080p
Touchscreen technology	Infrared
Contrast ratio (typical)	1100:1
Display number of colors	16.78 million colors
Display diagonal (metric)	138.8 cm
Active display area (W x H)	1209.6 x 680.4 mm
Number of simultaneous touchpoints	20
TV tuner integrated	No
Multi-display supported	-
Operating hours (hours/days)	24/7
On Screen Display (OSD) languages	CZE, DEU, DUT, ENG, FRE, JPN, POL, RUS
HDMI ports quantity	4
DisplayPorts quantity	0
VGA (D-Sub) input ports	1
RMS rated power	20 W
Number of built-in speakers	2
Certification	CE, CB, TÜV, CU
Orientation	Horizontal/Vertical
Product color	White
Product design	Digital signage flat panel
Panel mounting interface	400 x 400 mm
Cables included	AC, HDMI, USB, VGA
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	106 W
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 85 %
Harmonized System (HS) code	85285210

Weight and Dimensions

Depth	72 mm
Width	1265.6 mm
Height	736.5 mm
Weight	37500 g
