Iiyama ProLite TH5565MIS User Manual

ENGLISH
42 APPENDIX
APPENDIX
Design and specifi cations are subject to change without prior notice.
SPECIFICATIONS : ProLite TH5565MIS
*
USB peripherals / Audio equipment are not connected.
NOTE
Touch
Screen
Technology IR Touch 20points
Light transmission 88%
Communication system USB serial transfer
Size Category 55"
LCD
Panel
Panel technology IPS
Size Diagonal: 54.6" (138.8cm)
Pixel pitch 0.630mm H × 0.630mm V
Brightness 450cd/m
2
(Typical: without Touch panel)
Contrast ratio 1100 : 1 (Typical: without Touch panel)
Viewable angle Horizontal : 178 degrees, Vertical: 178 degrees (Typical)
Response time 12ms (Gray to Gray)
Display Colors Approx.16.7M
Sync Frequency
Analog: Horizontal: 30.0-83.0kHz, Vertical: 50-76Hz
Digital: Horizontal: 30.0-83.0kHz, Vertical: 50-76Hz
Maximum Resolution 1920 × 1080, 2.1 MegaPixels
Input Connector VGA(D-sub) mini 15 pin, HDMI×3
Input Video Connector RCA
Input Audio Connector mini jack, RCA (L/R)
Input Component Connector RCA (Video/L/R)
LAN RJ45
Serial Port RS-232C In/Out
Plug & Play VESA DDC2B
TM
Input Sync Signal Separate sync: TTL, Positive or Negative
Input Video Signal
Analog: 0.7Vp-p (Standard), 75

Positive
Digital: HDMI
Input Audio Signal 0.5Vrms maximum
IR Extender Connector IR In / Out
USB Connector USB2.0×2 (Media Player)
Output Connector HDMI
Output Video Connector RCA
Output Audio Connector RCA(L/R)
Speakers 10W×2 (Stereo speakers)
Maximum Screen Size 1209.6mm W × 680.4mm H / 47.6" W × 26.8" H
Power Source 100-240VAC, 50-60Hz, 1.8A
Power Consumption*
106W typical, Power management mode: 0.5W maximum
Energy Effi ciency Class: B
Dimensions / Net Weight
1265.5 × 736.5 × 72.0mm / 49.8 × 29.0 × 2.8" (W×H×D)
37.5kg / 82.7lbs

Iiyama ProLite TH5565MIS Specifications

General

Panel life	- h
Pixel pitch	0.63 x 0.63 mm
Response time	12 ms
Display diagonal	55 \
Display brightness	400 cd/m²
Display technology	LED
Native aspect ratio	16:9
Vertical scan range	50 - 76 Hz
Horizontal scan range	30 - 83 kHz
Supported video modes	1080p
Touchscreen technology	Infrared
Contrast ratio (typical)	1100:1
Display number of colors	16.78 million colors
Display diagonal (metric)	138.8 cm
Active display area (W x H)	1209.6 x 680.4 mm
Number of simultaneous touchpoints	20
TV tuner integrated	No
Multi-display supported	-
Operating hours (hours/days)	24/7
On Screen Display (OSD) languages	CZE, DEU, DUT, ENG, FRE, JPN, POL, RUS
HDMI ports quantity	4
DisplayPorts quantity	0
VGA (D-Sub) input ports	1
RMS rated power	20 W
Number of built-in speakers	2
Certification	CE, CB, TÜV, CU
Orientation	Horizontal/Vertical
Product color	White
Product design	Digital signage flat panel
Panel mounting interface	400 x 400 mm
Cables included	AC, HDMI, USB, VGA
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	106 W
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 85 %
Harmonized System (HS) code	85285210

Weight and Dimensions

Depth	72 mm
Width	1265.6 mm
Height	736.5 mm
Weight	37500 g
