Iiyama ProLite TH5565MIS User Manual

ENGLISH
40 TROUBLE SHOOTING
The screen is not
synchronized.

The Signal Cable is properly connected.

The signal timing of the computer is within the specifi cation of the monitor.

The video output level of the computer is within the specifi cation of the monitor.
The picture does
not appear.

The Power Cable is fi rmly seated in the socket.

The Power Switch is turned ON.

The AC socket is live. Please check with another piece of equipment.

If the blank screen saver is in active mode, touch the keyboard or the mouse.

Increase the Contrast and/or Brightness.

The computer is ON.

The Signal Cable is properly connected.

The signal timing of the computer is within the specifi cation of the monitor.

If the monitor is in power management mode, touch the keyboard or the mouse.
The screen
position is not in
the center.

The signal timing of the computer is within the specifi cation of the monitor.
The screen is too
bright or too dark.
The screen is
shaking.

The video output level of the computer is within the specifi cation of the
monitor.

The power voltage is within the specifi cation of the monitor.

The signal timing of the computer is within the specifi cation of the monitor.
No sound.

The audio equipment (computer etc.) is ON.

The Audio Cable is properly connected.

The Volume is turned up.

The Mute is OFF.

The audio output level of the audio equipment is within the specifi cation of
the monitor.
The sound is too
loud or too quiet.

The audio output level of the audio equipment is within the specifi cation of
the monitor.
A strange noise is
heard.

The Audio Cable is properly connected.
The touch
screen shows no
response.

The USB Cable is fi rmly seated in the socket.

Touch screen driver software is installed.
The touch position
does not deviate.

The calibration function set up correctly.
TROUBLE SHOOTING
Problem Check
If the monitor fails to operate correctly, please follow the steps below for a possible solution.
1. Perform the adjustments described in OPERATING THE MONITOR, depending on the problem
you have. If the monitor does not get a picture, skip to 2.
2. Consult the following items if you cannot fi nd an appropriate adjustment item in OPERATING THE
MONITOR or if the problem persists.
3.
If you are experiencing a problem which is not described below or you cannot correct the problem,
discontinue using the monitor and contact your dealer or iiyama service center for further assistance.

Iiyama ProLite TH5565MIS Specifications

General

Panel life	- h
Pixel pitch	0.63 x 0.63 mm
Response time	12 ms
Display diagonal	55 \
Display brightness	400 cd/m²
Display technology	LED
Native aspect ratio	16:9
Vertical scan range	50 - 76 Hz
Horizontal scan range	30 - 83 kHz
Supported video modes	1080p
Touchscreen technology	Infrared
Contrast ratio (typical)	1100:1
Display number of colors	16.78 million colors
Display diagonal (metric)	138.8 cm
Active display area (W x H)	1209.6 x 680.4 mm
Number of simultaneous touchpoints	20
TV tuner integrated	No
Multi-display supported	-
Operating hours (hours/days)	24/7
On Screen Display (OSD) languages	CZE, DEU, DUT, ENG, FRE, JPN, POL, RUS
HDMI ports quantity	4
DisplayPorts quantity	0
VGA (D-Sub) input ports	1
RMS rated power	20 W
Number of built-in speakers	2
Certification	CE, CB, TÜV, CU
Orientation	Horizontal/Vertical
Product color	White
Product design	Digital signage flat panel
Panel mounting interface	400 x 400 mm
Cables included	AC, HDMI, USB, VGA
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	106 W
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 85 %
Harmonized System (HS) code	85285210

Weight and Dimensions

Depth	72 mm
Width	1265.6 mm
Height	736.5 mm
Weight	37500 g
