Iiyama ProLite TH5565MIS User Manual

ENGLISH
46 APPENDIX
COMPLIANT TIMING
* means supported the timing.
Timing
VESA
VGA 640x480
31.469 59.940 25.175
37.861 72.810 31.500
37.500 75.000 31.500
SVGA 800x600
35.156 56.000 36.000
37.879 60.320 40.000
48.076 72.000 50.000
46.875 75.000 49.500
XGA 1024x768
48.363 60.000 65.000
56.475 70.000 75.000
60.023 75.030 78.750
1280x768 47.776 59.870 79.500
1280x768 RB 47.400 60.000 68.250
1280x768 60.060 75.000 78.800
WXGA 1280x800
49.702 59.810 83.500
62.800 75.000 106.500
SXGA 1280x1024
63.981 60.020 108.000
79.976 75.000 135.000
1360x768 47.712 60.020 85.500
1440x900 55.919 60.000 106.470
FHD 1920x1080 67.500 60.000 148.500
SD
NTSC-M 15.734 59.940 13.500
NTSC-J 15.734 59.940 13.500
PAL-BDGHI 15.734 59.940 13.500
720x480i 60Hz 15.734 59.940 13.500
720x576i 50Hz 15.625 50.000 13.500
720x480p 60Hz 31.469 59.940 27.000
720x576p 50Hz 31.250 50.000 27.000
HD
1280x720p
50Hz 37.500 50.000 74.250
60Hz 45.000 60.000 74.250
1080i
50Hz 28.125 50.000 74.250
60Hz 33.750 60.000 74.250
1080p
24Hz 27.000 24.000 74.250
25Hz 28.125 25.000 74.250
30Hz 33.750 30.000 74.250
50Hz 56.250 50.000 148.500
60Hz 67.500 60.000 148.500
1440x576p 50Hz 31.250 50.000 27.000
1440x480p 60Hz 31.250 60.000 27.027
fH(kHz)
fV(Hz) Dot clock (MHz)
HDMI
VGA YPbPr
AV
M168A21

Iiyama ProLite TH5565MIS Specifications

General

Panel life	- h
Pixel pitch	0.63 x 0.63 mm
Response time	12 ms
Display diagonal	55 \
Display brightness	400 cd/m²
Display technology	LED
Native aspect ratio	16:9
Vertical scan range	50 - 76 Hz
Horizontal scan range	30 - 83 kHz
Supported video modes	1080p
Touchscreen technology	Infrared
Contrast ratio (typical)	1100:1
Display number of colors	16.78 million colors
Display diagonal (metric)	138.8 cm
Active display area (W x H)	1209.6 x 680.4 mm
Number of simultaneous touchpoints	20
TV tuner integrated	No
Multi-display supported	-
Operating hours (hours/days)	24/7
On Screen Display (OSD) languages	CZE, DEU, DUT, ENG, FRE, JPN, POL, RUS
HDMI ports quantity	4
DisplayPorts quantity	0
VGA (D-Sub) input ports	1
RMS rated power	20 W
Number of built-in speakers	2
Certification	CE, CB, TÜV, CU
Orientation	Horizontal/Vertical
Product color	White
Product design	Digital signage flat panel
Panel mounting interface	400 x 400 mm
Cables included	AC, HDMI, USB, VGA
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	106 W
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 85 %
Harmonized System (HS) code	85285210

Weight and Dimensions

Depth	72 mm
Width	1265.6 mm
Height	736.5 mm
Weight	37500 g
