3. Multi-function knob and LED ring
This single knob allows you to control all the features of the microphone including microphone gain, mute,
headphone volume, overall streaming level, loopback, monitor blend mix, patterns and HPF.
Important Note: each time the knob is pressed, the capsule signal will be temporarily muted for about 500 ms
in order to minimize the vibration noise transmitted to the audio stream.
3.1 Microphone gain control
When the microphone symbol is lit green, the knob will control the microphone gain and the LED ring will show
the peak level of the microphone’s capsule signal.
When you move the knob to increase or decrease the microphone gain, the LED ring will temporarily show
the gain level you are setting. After 2 seconds the LED ring will return showing the peak level. For the best
performance, set the gain so that your loudest speech peaks at the second half of the LED ring (around LED nr.
7 or 9).
If a clip will occur the microphone symbol will light red for 2 seconds.
for 1 sec.
By pushing and holding the knob for 1 second, the signal of the microphone’s capsules will be muted. When the
mic is muted, the microphone symbol will blink orange. The LED ring will continue to show the peak level of the
overall streamed signal with the same logic described above.
Muting and unmuting works in all modes.
Press the knob to get to the Headphone volume control.
